Graco Reactor 2

Graco's Reactor A-25 air-driven foam proportioner, ideal for spraying foam insulation. The Reactor A-25 maintains consistent temperature control, even when spraying at maximum flow rates - resulting in better quality foam on site.
  • Maintains temperature set-points for better yield
  • Maintains consistent output pressure for uniform spray pattern
  • Easy to operate and maintain
  • Best choice for affordability and durability
Specifications Downloads Custom Tab
Air requirements: 28 scfm (12 l/sec)
Heater wattage and power (6.0kW heater): 40A-230V, 1-ph; 32A-230V, 3-ph; 18.5A-380V, 3-ph
Maximum output: 25 lb/min (11.4 kg/min)
Maximum fluid working pressure: 2000 psi (138 bar, 13.8 MPa)
Maximum fluid temperature: 190° F (88° C)
Maximum hose length: 210 ft (64 m)
Applications: Wall insulation, roof insulation, in-plant OEM, adhesives and caulk, rim and band jois
